designing gears safely
MDESIGN gear
MDESIGN gear
Calculate gearings for all applications
On the basis of currently valid standards (DIN, ISO, AGMA), calculation regulations (VDI) and technical literature, the calculation tools contained in MDESIGN gear enable you to verify extended gearings in a technically correct manner. MDESIGN supports you in the design, recalculation and optimization of:
- Spur gear calculations according to AGMA and ISO
- Bevel hypoid gear calculations according to AGMA and DNV
- Plastic gears
- Screw gears
- Crown gears
- Ring gears with rim influence
- Micropitting load capacity for spur gear pairs
- Tooth flank fracture
- Torsional backlash
- Test dimensions
Transparency and documentation
With graphics, notes and closed calculation documentation, MDESIGN offers you complete transparency for determining results. Whether in HTML, RTF or PDF/A format, the results documentation created in MDESIGN contains the calculation results, underlying methods, calculation rules and standards, geometry and material data as well as graphical evaluations.
Variant calculation for optimization
To enable you to carry out variant calculations in the shortest possible time, MDESIGN includes the option of parametric analysis. Here, the input variables of a calculation are automatically varied and the number and size of the steps for each input variable can be freely selected. The effects of the varying inputs on the calculation results can then be interpreted quickly and accurately with the help of the clear display.
Versatile in use
MDESIGN 3D model for CAD export
